| Tip material / diameter | 2 mm/4 mm/10 mm stainless steel tip |
|---|
| Work function resolution | 1 - 3 meV |
|---|
| Sample scanning | 20 x 20 mm stepper motor controlled |
|---|
| Mounting geometry | Normal to sample surface |
|---|
| Tip retraction | 100 mm |
|---|
| Visualisation | 3D map of surface potential and sample topography |
|---|
| Oscilloscope | Digital TFT oscilloscope for real time signal |
|---|
| Step size | 0.5 µm (Z); 2.5 µm (X,Y) |
|---|
| Tracking system | Automatic hold of tip-to-sample distance to 0.5 µm |
|---|
| Detection system | Off-null with parasitic capacity rejection |
|---|
| Mounting geometry | Normal to sample surface |
|---|
| Mounting flange | DN63 (4.5") OD |
|---|
| Vacuum compatibility | 2 x 10-11 mBar |
|---|
| Digital control of | Tip amplitude, frequency, mean spacing and potential |
|---|
| System includes | Set-up guide, cables and manual |
|---|
| Averaging | Signal and work function |
|---|
| Spare tip amplifier | Included |
|---|
| Warranty | 12 months |
|---|
